PY series pneumatic fittings

Hered PY Series Tee Connector Pneumatic Quick Connect Pipe Tube Fittings: Versatile branching connectors for complex pneumatic systems. Features high-strength plastic construction, quick-connect design, and excellent sealing. Available in sizes PY-4 to PY-16, compatible with 4mm to 16mm tubing. Operates at 0°C-60°C with max pressure 1.32Mpa. Suitable for normal (0-0.9Mpa) and low pressure (-99.99-0Mpa) ranges. Compatible with PU/nylon tubing. Ideal for manufacturing, automotive, food processing, construction, energy, mining, and HVAC industries. Offers tool-free installation, high burst resistance, and long service life. Engineered for durability and easy maintenance in demanding industrial environments. Perfect for applications requiring efficient, leak-free tee connections in pneumatic setups. Combines quick-connect convenience with wear and corrosion resistance for optimal performance. Cost-effective solution for complex air distribution systems, ensuring reduced downtime and simplified maintenance in various industrial applications.

Send your requirements, we will quote for you within 12 hours

Tel:+8618066396588

Hered PY Series Tee Connector Pneumatic Quick Connect Pipe Tube Fittings

The Hered PY Series Tee Connector Pneumatic Quick Connect Pipe Tube Fittings offer a versatile and efficient solution for branching pneumatic connections in various industrial applications. These high-quality fittings combine durability with ease of use, making them an excellent choice for complex pneumatic systems.

Key Features

  • High-strength plastic construction
  • Wear and corrosion-resistant
  • Quick-connect design for easy installation
  • Tool-free insertion and removal of tubing
  • Excellent sealing performance
  • Wide range of applications in pneumatic systems
  • Long service life and durability
  • Compatible with PU and nylon tubing

Technical Specifications

Parameter Specification
Fluid Air
Max. Pressure 1.32Mpa (13.5kgf/cm²)
Normal Pressure Range 0~0.9Mpa (0~9.2kgf/cm²)
Low Pressure Range -99.99~0Mpa (-750~0mmHg)
Operating Temperature 0°C ~ 60°C
Tube Outer Sizes 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm
Metric Type φD B J φd
PY-4 4 36 11 2.5
PY-6 6 39 13 3.5
PY-8 8 43 15 4
PY-10 10 49 19 4
PY-12 12 54 21 4
PY-14 14 53 23.5 4
PY-16 16 63 27 4

Available Models

The PY Series includes a range of sizes to accommodate various tubing diameters:

  • PY-4 (4mm), PY-6 (6mm), PY-8 (8mm)
  • PY-10 (10mm), PY-12 (12mm), PY-14 (14mm), PY-16 (16mm)

Applications

Ideal for various pneumatic systems in:

  • Manufacturing plants
  • Automotive industry
  • Food & beverage processing
  • Construction works
  • Energy & mining operations
  • HVAC systems
  • General industrial automation

Benefits

  • Quick and easy installation with tool-free design
  • High-density construction ensures resistance to bursting
  • Versatile use with different pneumatic components
  • Excellent sealing performance to prevent leaks
  • Cost-effective solution for pneumatic pipe connections
  • Reduced maintenance and downtime

Quality Assurance

Hered Pneumatic Co., LTD. ensures high-quality production using premium PU raw materials. Our PY Series fittings are designed for stable performance, high pressure resistance, and weather resistance, meeting the demands of various industrial environments.

For detailed sizing information, installation guidelines, or to place an order, please contact our customer support team.
