Product Overview
The Hered PL Series Stainless Steel Male Elbow Pneumatic Fittings are high-performance quick connect couplings designed for efficient and reliable fluid transfer in pneumatic systems. These innovative fittings combine durability, ease of use, and versatility, making them essential components for various industrial applications.
Key Specifications
| Feature | Specification |
|---|---|
| Product Name | Stainless Steel Coupling |
| Product Series | PL Series |
| Material | Stainless Steel |
| Working Pressure | 132 MPa (13.5 kgf/cm²) |
| Operating Pressure | Within 10 kg |
| Temperature Range | 0~60°C |
| Applicable Media | Water, Steam, Oil, etc. |
| Compatible Tubing | PU tubing, Nylon tubing |
Key Features
- Corrosion Resistance: Made from high-grade stainless steel for superior durability in harsh environments.
- Quick Connect Design: Allows for rapid, tool-free connections and disconnections.
- Male Elbow Configuration: 90-degree angle design for efficient routing of pneumatic lines in tight spaces.
- High Pressure Capacity: Suitable for use in high-pressure systems up to 132 MPa.
- Wide Temperature Range: Performs efficiently in temperatures from 0 to 60°C.
- Versatile Media Compatibility: Suitable for water, steam, oil, and other fluids.
Applications
Hered PL Series Stainless Steel Male Elbow Pneumatic Fittings are ideal for use in:
- Pneumatic systems
- Air supply lines for tools and equipment
- Industrial automation
- Manufacturing processes
- Fluid and gas transfer systems
- Steam applications
- Oil hydraulic systems
Advantages
- Enhanced Efficiency: Quick connect mechanism saves time during system changes or maintenance.
- Improved Space Management: 90-degree elbow design allows for compact pneumatic line routing.
- Versatile Application: Suitable for various fluids and gases in different industrial settings.
- Durable Performance: Stainless steel construction ensures long-lasting reliability.
- Easy Installation: Push-to-connect feature eliminates the need for special tools during installation.
- Compatibility: Works with both PU and nylon tubing for flexible system design.
Installation Tips
For optimal performance of Hered PL Series Stainless Steel Male Elbow Pneumatic Fittings:
- Ensure proper sizing and thread matching when connecting to system components.
- Use appropriate thread sealant or PTFE tape for a leak-free connection if required.
- Verify that the connection is fully secured before pressurizing the system.
- Do not exceed the maximum pressure rating of 132 MPa.
- Operate within the specified temperature range of 0~60°C.
- Regularly inspect fittings for signs of wear or damage.
- Follow manufacturer guidelines for specific installation and maintenance requirements.
Note: All dimensions are manually measured. Please refer to the actual product for precise measurements.
The Hered PL Series Stainless Steel Male Elbow Pneumatic Fittings represent a significant advancement in pneumatic connection technology. Their robust design, user-friendly operation, and versatile application range make them essential components for businesses seeking to enhance the efficiency, safety, and reliability of their industrial fluid and pneumatic systems across various applications.
