CQS Series Compact Cylinder

Hered CQS Series Compact Cylinder: Space-efficient, high-performance pneumatic actuator for diverse industrial applications. Available in bore sizes 12mm to 25mm, with strokes from 5mm to 500mm (up to 1400mm for long stroke). Operates at -10°C to 60°C, pressure range 0.1-1.0MPa, and speeds of 50-500mm/s. CE certified. Features direct mounting capability, auto switch mounting on multiple sides, and high lateral load resistance. Offers various configurations: double/single acting, double rod, non-rotating rod, and anti-lateral load types. Ideal for automated machinery, robotic arms, packaging lines, and material handling systems. Combines compact design with durability and reliability. Suitable for space-constrained setups requiring robust pneumatic solutions. Engineered for versatility and easy integration, enhancing operational efficiency in demanding industrial environments. Perfect for applications needing precise, reliable actuation in limited spaces. Backed by Hered Pneumatic’s expertise and comprehensive support services.

Send your requirements, we will quote for you within 12 hours

Tel:+8618066396588
Whatsapp:+8618066396588
Email:sales@hered.com
Get quote

CQS Series Compact Cylinder

The CQS Series Compact Cylinder from Hered Pneumatic Co., LTD. delivers exceptional performance in a space-saving design for diverse industrial applications. This CE-certified pneumatic cylinder offers a lightweight yet robust solution, capable of withstanding significant lateral loads while maintaining an elegant appearance.

Key Features

Compact structure for space-efficient installations
Direct mounting capability, eliminating need for additional accessories
High-quality materials ensuring durability and reliability
Available in multiple configurations and stroke lengths
Auto switch mountable on 3 or 4 sides (bore size dependent)
CE certified for quality assurance

Technical Specifications

Specification Details
Bore Sizes 12, 16, 20, 25 mm
Operating Pressure 0.1-1.0 MPa
Working Temperature -10°C to 60°C
Speed Range 50-500 mm/s
Standard Stroke Lengths 5-50 mm (ø12, ø16), 5-500 mm (ø20, ø25)
Long Stroke Range 1-1400 mm

Available Configurations

CQS: Double Acting, Single Rod
CQS: Single Acting, Spring Return/Extend
CQSW: Double Acting, Double Rod
CQSK: Non-Rotating Rod, Double Acting, Single Rod
CQSKW: Non-Rotating Rod, Double Acting, Double Rod
CQS□S: Anti-Lateral Load Type, Double Acting, Single Rod

Applications

The CQS Series Compact Cylinder excels in:

Automated machinery systems
Robotic arms and precision equipment
Packaging and assembly lines
Material handling and transfer systems
Space-constrained industrial setups

Hered Pneumatic Advantage

By choosing the CQS Series from Hered Pneumatic Co., LTD., you’re investing in:

Innovative space-saving design
Versatile mounting options
Reliable performance in demanding environments
CE-certified quality and safety standards

Support and Service

Our team of pneumatic experts is ready to assist you with product selection, technical support, and after-sales service. Contact Hered Pneumatic Co., LTD. today to discover how the CQS Series Compact Cylinder can optimize your pneumatic systems and enhance your operational efficiency.
